BRACKETS & ACCESSORIES

IF IT NEEDS SUPPORT, WE’VE GOT THE PILE CAP.

Float-Image-Filler

IF IT NEEDS SUPPORT, WE’VE GOT THE PILE CAP.

IF WE DON’T HAVE IT, WE MAKE IT. IT’S THAT SIMPLE.

IDEAL manufactures a wide range of stock and custom fabricated new construction and foundation remediation/repair brackets.

The IDEAL team is often called on to design and fabricate brackets to exact client specifications. This is another area where our design and production teams have become highly recognized for their innovation and skill.

Our highly efficient production processes and principles combined with our commitment to consistent quality allow us to provide foundation brackets with some of the shortest lead times in the industry.

Our unique approach to design and production allows us to provide you numerous benefits whether you’re an installer, contractor, or engineer. Pair our brackets with STELCOR® piles and our expert-engineered helical piles for unbeatable building support.
GET IN TOUCH WITH US if you have any questions surrounding our pile and support brackets and accessories.
new_construction

STANDARD NEW CONSTRUCTION CAPS

TENSION CAPS – single or double bolted for tension or uplift requirements
COMPRESSION CAPS with gravity ‘slip-on’ design. Custom plate sizes, rebar attachments, and bolted versions are also available.

tieback_adapter

TENSION ANCHORS / TIEBACK ADAPTERS

DEFORMED THREADBAR with structural nuts and embedment plates.
U-SHAPED offers increased adjustability when perfect alignment is is required.
COUPLING anchors are good in tight areas or where angulation is predictable.

underpinning_bracket

UNDERPINNING BRACKETS FOR EXISTING FOUNDATIONS

COUNTERFORCE II BRACKETS are used for high eccentricity and high service loads up to 40 kips*.
COUNTERFORCE BRACKETS are used for high eccentricity and moderate service loads up to 30 kips*. This bracket is standard for pile diameters greater than 3.5”.
TRU-FORCE BRACKETS are used for moderate eccentricity and service loads up to 20 kips*.
LOW-PRO DROP-NECK BRACKETS are used for shallow footing situations.
BRACE PLATE BRACKETS are used for secure foundation attachment on TruForce and CounterForce brackets.

basic_boardwalk_bracket

TIMBER/BEAM BRACKET

COMPRESSION BRACKET is a standard U-shape saddle bracket.
COMPRESSION/TENSION BRACKETS are standard U-shape saddle brackets with thru-bolt(s) to pile.
ADJUSTABLE BRACKETS are any bracket with additional threadbar post to underside of saddle with a matching receptacle in the top of the pile.
ARTICULATING ADJUSTABLE BRACKETS are used when a pile is out-of-plumb and out-of-position.
CUSTOM FABRICATED BRACKETS are used for multiple beam sizes – timber or steel selection.

pipe-saddles

PIPE SADDLES

FULLY ADJUSTABLE BRACKET can be used where heavy pipes need to be pitched perfectly to make grades. No shimming, or removal needed to set to within .125”.
STANDARD PIPE SADDLE BRACKET is used when piles are set to exact requirements. A T-bracket is used with beams or saddle.

custom_specialty_brackets

CUSTOM + SPECIALTY BRACKETS

REBAR CAPS – Shearhead with welded rebar for easy cage tie-offs.
CUSTOM CONNECTIONS TO PREFABRICATED UNITS such as clearspan steel buildings, light pole bases, etc.
SHOREHOUSE BRACKETS were developed for Superstorm Sandy remediations. Provides reliable support and positioning for beams and timbers for positive attachment to resist uplift/lateral/axial loads.
ADJUSTABLE custom brackets for many applications.
SOLAR bracket systems for speedy solar installations. Pile size and capacity will govern the final design of any pile LTD (Load Transfer Device).
